Dragging Cable Powered Transfer Cart On Rail Steel Metal Transporter
Introduction of Dragging Cable Powered Transfer Cart
This type of transfer cart is powered by dragging cable. The power source is leaded into electrical control cabinet by cable, which controls the motor to make the car star, stop, move forward, move backward. The cable is laid between two rails and the operation voltage is 36V. PLC system can be mounted on the car to realize full automation operation. It can be applied in the occasion such as high temperature,anti-explosive environment. We accept customization.
Application Sites of Dragging Cable Powered Transfer Cart
These workshops are always need our product such as assembly line(ring production line, loop production line), metallurgy industry (steel ladle), warehouse transport, ship industry (maintenance, assemble, container transport), workpiece transport in workshop, lathe transport, steel factory(steel billet, steel plate, steel coil, steel pipe, section steel, steel structure), construction(bridge, simple building, concrete, concrete column), petroleum industry(oil pump, sucker rod and parts), energy (polycrystalline silicon, generator, windmill), chemical industry(electrolytic cell, retort etc), railway(rail maintenance, rail welding, train tractor). We promise to supply the perfect scheme for you.
Parameter of Dragging Cable Powered Transfer Cart
| Model | BTL-2t | BTL -20t | BTL -50t | BTL -100t | BTL -150t |
| Rated Load(t) | 2 | 20 | 50 | 100 | 150 |
| Table Size (mm) | Length(L) | 2000 | 4000 | 5500 | 6500 | 10000 |
| Width(W) | 1500 | 2200 | 2500 | 2800 | 3000 |
| Height(H) | 450 | 550 | 650 | 850 | 1200 |
| Wheel Base(mm) | 1200 | 2800 | 4200 | 4900 | 7000 |
| Rail Inner Gauge(mm) | 1200 | 1435 | 1435 | 2000 | 2000 |
| Wheel Diameter(mm) | 270 | 350 | 500 | 600 | 600 |
| Wheel Quantity | 4 | 4 | 4 | 4 | 8 |
| Ground Clearance(mm) | 50 | 50 | 50 | 75 | 75 |
| Running Speed(min) | 0-25 | 0-20 | 0-20 | 0-20 | 0-18 |
| Motor Power(kw) | 0.8 | 2.5 | 5.5 | 11 | 15 |
| Recommended Rail Model | P15 | P24 | P43 | QU100 | QU100 |
Our Other Products
Henan Perfect Handling Equipment Co., Ltd produce vary type of transfer car to meet all wrokshop demands.All our product are customized according to customer's different need.Such as Automotive, Basic Metals, Heavy Manufacturing, Rigging, Stamping, and more.
Package And Transportation
The body of the cart is packed with tarp, the small parts will be packed with wooden cases. According the table size and quantity, the cart would be carefully fixed and transported by FCL, LCL, Bulk Transportation, Open Top Container, Flat Rack Container and so on.
Why Choose Us?
1. We are professional design and manufacture transfer cart company.with 15 years experience in this fields.
2. We guarantee high quality product,we do care worker's safe.
3. Our warranty is 12 months, during this period, we can maintance is for you freely, after that period,we only charge cost price.
4. Various modes including email, telephone, and online for operating guidance.
5. Flexible payment method for customers' choice.
6. Excellent engineers' team are available at the any time for customers' questions.
