Stainless steel Industrial Transfer Trolley / heavy duty railway motorized transfer trolley

Name: Stainless steel Industrial Transfer Trolley heavy duty railway motorized transfer trolley
Brand: PERFECT
Price: 2000 USD

Wholesale Stainless steel Industrial Transfer Trolley / heavy duty railway motorized transfer trolley from china suppliers

Brand Name : PERFECT

Model Number : BTL

Certification : CE ISO SGS

Place of Origin : China(Mainland)

MOQ : 1 set

Price : USD 2000~40000 set

Payment Terms : L/C, T/T

Supply Ability : 100 sets month

Delivery Time : 20 work days after received balance payment

Packaging Details : trap and wooden case

Product Name : steel heavy duty railway motorized transfer trolley

Item : Cart

Material : Q235

Capacity : Customized

after-sales Service Provided : Engineers available to service machinery

Running speed : 0-20m/min

Certificates : CE ISO SGS

Contact Now

Stainless steel Industrial Transfer Trolley / heavy duty railway motorized transfer trolley

Stainless steel heavy duty railway motorized transfer trolley

Stainless steel heavy duty railway motorized transfer trolleyis usually used at ship yard, plant and factory, certain production line. The railway motorized transfer trolley is powered by trailing cable. The railway motorized transfer trolley was developed to dramatically reduce the material handling requirements of cranes and fork trucks while providing quick, safe and smooth movement of materials and/or products through manufacturing facilities. railway motorized transfer trolley construction is based on our world renowned die railway motorized transfer trolleys and provides controlled movement of heavy and oversized loads such as dies, coils and work in progress. Our railway motorized transfer trolley is available in a number of configurations specifically designed to suit the needs of our customers.

Stainless steel Industrial Transfer Trolley / heavy duty railway motorized transfer trolley

Technical Parameter of railway motorized transfer trolley

Model		BTL-2t	BTL-20t	BTL-50t	BTL-100t	BDGS-150t
Rated Load(t)		2	20	50	100	150
Table Size(mm)	Length(L)	2000	4000	5500	6500	10000
	Width(W)	1500	2200	2500	2800	3000
	Heigth(H)	450	550	650	850	1200
Wheel Base(mm)		1200	2800	4200	4900	7000
Rail Inner Gauge(mm)		1200	1435	1435	2000	2000
Wheel Diameter(mm)		270	350	500	600	600
Wheel Quantity		4	4	4	4	8
Ground Clearance(mm)		50	50	50	75	75
Running Speed(min)		0-25	0-20	0-20	0-20	0-18
Motor Power(kw)		0.8	2.5	5.5	11	15
Running Distance(m)		0-20
Max Wheel Load(KN)		14.4	77.7	174	343.8	265.2
Reference Weight(t)		2.3	5.5	7.6	13.9	26
Recommended Rail Model		P15	P24	P43	QU100	QU100

Detial of railway motorized transfer trolley

Stainless steel Industrial Transfer Trolley / heavy duty railway motorized transfer trolley

NOTES:

Flat deck or fixtures for transporting special payload;
Custom deck configurations may include lift, tilt, or rotate function;
Payload from 1 ton to 300 tons;
Fixed speed or variable speed capabilities;
With forward or backing driving;
Options for automatic control;
Available safety equipment includes horn, lights, emergency stop, bumpers and detector.

Components of railway motorized transfer trolley

Stainless steel Industrial Transfer Trolley / heavy duty railway motorized transfer trolley

Technical Process of railway motorized transfer trolley

1. Moving the steel plate from storage area to cutting process area by crane;
2. According to the cutting drawing cutiting steel plate by the numercial control cutting machine;
3. The mobile welding machine is used for precise welding of diferent parts of the frame;
4. Fine grinding and weld inspection of the weld joint;
5. For every car primer spray, toccat, perfect antirust, ensure th ebeauftiful appearance;
6. Installation of the whole internal parts of the wheel and the car body;
7. Commissioning the vehicle operation and electrical parts, then test after completion of commissoning:
8. Zero load test and load test before shipping.

Stainless steel Industrial Transfer Trolley / heavy duty railway motorized transfer trolley

Application Sites of railway motorized transfer trolley

The railway motorized transfer trolley is mainly applied in assembly line(ring production line,loop production line),metallurgy industry(steel lade),warehouse transport,ship industry(maintenance, assemcle,container transport),work piece transport in workshop,lathe transport,steel factory(steel billet,steel plate,steel coil,steel pipe,section steel structure),construction(bridge,simple building,concrete column,)petroleum industry(oil pump,sucker rod and parts),energy(polycrystalline silicon,generator,windmill),chemical industry(electrolytic cell,retort etc),railway(rail maintenance,rail welding,train tractor).

Customers Visiting

Stainless steel Industrial Transfer Trolley / heavy duty railway motorized transfer trolley

Package of railway motorized transfer trolley

Our railway motorized transfer trolley not only have sold across the country, but also exported to US, Germany, Thailand, Netherlands, South Africa, Syria, Turkey, Nepal etc. The railway motorized transfer trolley body is packed with tarp, and the wheel and parts of the railway motorized transfer trolley will be packed with wooden case. According the table size and quantity, the railway motorized transfer trolley would be transported to clients by FCL, LCL, Bulk Transportation, Open Top Container, Flat Rack Container and so on.

Stainless steel Industrial Transfer Trolley / heavy duty railway motorized transfer trolley

Certificates

Stainless steel Industrial Transfer Trolley / heavy duty railway motorized transfer trolley

Our Factory

Stainless steel Industrial Transfer Trolley / heavy duty railway motorized transfer trolley

Product Tags:

electric transfer cart

material transfer trolley

Stainless steel Industrial Transfer Trolley / heavy duty railway motorized transfer trolley Images
