2T cable drum powered rail track factory flat transfer carts can be customizeable
Description
This series of cable drum powered adopt box girder structure, which has the advantages of strong bearing capacity, no distortion, stable start, large starting moment, small impact on reducer, low voltage, long service life, unlimited running distance, and low requirement for track laying. Compared with KPJ, KPD, KPC and KPT series rail track factory flat transfer carts, 2T cable drum powered rail track factory flat transfer carts has more safety and motor flexibility. 2T cable drum powered rail track factory flat transfer carts is suitable for the occasions of low frequency and medium and long distance transportation.
Functions of 30t Rail powered transfer flat cart:
I:Strong bearing capacity
II.No distortion, smooth start
III.large start moment, small impact on reducer
V.low voltage, long service life,
IV:unlimited running distance, low requirement for track laying
Product parameters
| Modle | BTL-10T | BTL-30T | BTL-50T | BTL-80T | BTL-100T | BTL-150T |
| Table Size (m) | 3.4*2.1*0.5 | 4.6*2.2*0.6 | 5.7*2.5*0.65 | 6.1*2.6*0.8 | 6.5*3.8*0.9 | 10*3.2*1.2 |
| Power | Maintenance Free Battery |
| Rail inner Gauge | 1435mm | 1435mm | 1435mm | 1800mm | 2000mm | 2000mm |
| Wheel Dia. | 350mm | 400mm | 500mm | 600mm | 600mm | 600mm |
| Running Speed | 0-25m/min | 0-25m/min | 0-25m/min | 0-25m/min | 0-25m/min | 0-25m/min |
| Motor Power | 1.6kw | 3.5kw | 5kw | 8kw | 10kw | 15kw |
| Battery Capacity | 180Ah | 250Ah | 330Ah | 400Ah | 440Ah | 600Ah |
| Battery Volatge | 48v | 48v | 48v | 72v | 72v | 72v |
| Max Wheel Load | 42.6Kn | 110.4Kn | 174Kn | 278.4Kn | 343.8Kn | 265.2Kn |
| Reference weight | 4.2t | 6.8t | 8t | 12.8t | 14.6t | 26.8t |
| Recommend Rail | P24 | P38 | P43 | P50 | QU100 | QU100 |
Application
Matters needing attention
2T cable drum powered rail track factory flat transfer carts are powered by 380V AC cable drum. The cable drum is of hysteresis coupling type, which ensures that the cable is uniformly stressed and not easily damaged. AC 380V provides electric power for YZ crane metallurgical motor on flat car, and the motor drives the flat car to run. When 2T cable drum powered rail track factory flat transfer carts is running, the cable drum automatically rolls up or releases the cable, which is affected by the power supply length of the drum, and the maximum running distance is usually less than 200 m.
